Adam Audio S5H Studio Monitor

The Adam Audio S5H Studio Monitor delivers uncompromising precision, massive headroom, and breathtaking detail for professional recording, mixing, and mastering environments where every sonic decision matters.

As ADAM Audio's flagship horizontal three-way reference monitor, the S5H combines dual 10-inch woofers, an innovative DCH midrange driver, and a handcrafted S-ART tweeter to deliver exceptional clarity, powerful low-frequency reproduction, and a remarkably natural listening experience. Designed for large control rooms and demanding audio professionals, this powerhouse studio monitor provides the accuracy and dynamic performance needed to hear every nuance of a mix with confidence. When your studio demands reference-quality sound without compromise, the S5H is ready to deliver. At the heart of the ADAM Audio S5H is an advanced three-way design engineered to reproduce the entire frequency spectrum with exceptional control and consistency. Two 10-inch Extended Linear Excursion (ELE) woofers utilize ADAM Audio's proprietary Symmetrical Magnet Assembly (SMA) technology to deliver deep, articulate bass while minimizing distortion. The specially developed 4-inch Dome/Cone Hybrid (DCH) midrange driver combines the advantages of traditional dome and cone designs, producing outstanding midrange definition and accuracy. Completing the system is ADAM Audio's precision-built S-ART tweeter, which delivers extended high-frequency detail without introducing the harshness or fatigue that can make long mixing sessions exhausting. Dedicated MPS and HPS waveguides maintain consistent dispersion and a broad listening sweet spot, making the S5H particularly well suited for collaborative sessions in larger studios. The S5H also incorporates sophisticated onboard DSP processing, giving engineers extensive control over how the monitor performs in their listening environment. Custom-designed digital crossovers optimize driver integration, while six parametric EQ bands, dedicated high- and low-shelf room compensation filters, and multiple preset memories allow precise acoustic adjustments. Additional functionality includes adjustable input sensitivity, delay compensation, and high-frequency driver protection. Analog XLR and AES3 digital connectivity provide flexibility for modern studio installations, while USB connectivity supports firmware updates and computer-based DSP control. With dedicated amplification for each frequency range and a total of 1,100 watts of RMS power, the ADAM Audio S5H delivers tremendous dynamic range, effortless transient reproduction, and the kind of authoritative monitoring performance that professional studios rely on every day.

Adam Audio S5H Studio Monitor Features

• Flagship three-way active studio monitor designed for professional recording, mixing, and mastering applications
• Horizontal cabinet configuration optimized for large control rooms and main monitoring installations
• Dual Extended Linear Excursion (ELE) woofers deliver powerful, controlled bass with exceptional low-frequency accuracy
• Proprietary Symmetrical Magnet Assembly (SMA) technology minimizes distortion and improves bass driver performance
• Innovative Dome/Cone Hybrid (DCH) midrange driver provides outstanding clarity and natural reproduction of critical midrange frequencies
• Handcrafted S-ART tweeter delivers exceptional high-frequency detail with smooth, fatigue-free listening characteristics
• High-frequency Propagation System (HPS) waveguide promotes consistent dispersion and accurate stereo imaging
• Mid-range Propagation System (MPS) waveguide maintains controlled midrange dispersion across the listening area
• Wide listening sweet spot accommodates multiple engineers and producers working together
• Dedicated amplification for each driver section provides substantial headroom and precise dynamic control
• Advanced onboard DSP optimizes crossover performance and allows extensive acoustic tuning
• Parametric equalization and dedicated room compensation filters help tailor monitor response to the listening environment
• User-configurable presets allow convenient switching between different monitoring configurations
• Adjustable input sensitivity and delay settings provide additional system integration flexibility
• Integrated high-frequency protection helps safeguard the tweeter during demanding sessions
• Analog XLR and AES3 digital inputs support professional studio connectivity
• USB connectivity enables firmware updates and computer-based DSP adjustments
• Heavy-duty cabinet construction helps minimize unwanted resonance and coloration
• Advanced bass reflex design reduces port turbulence and improves low-frequency performance
• Engineered for accurate reference monitoring in high-end production and mastering facilities

Adam Audio S5H Studio Monitor Specifications

• Speaker Type: Three-Way Active Studio Monitor
• Orientation: Horizontal
• Frequency Response: 22 Hz – 50 kHz (-20 dB)
• Maximum SPL per Pair at 1 m: ≥131 dB
• Crossover Frequencies: 250 Hz, 3 kHz
• Total RMS Amplifier Power: 1100 W
• Analog Input: XLR
• Digital Input: AES3
• Input Impedance: 48 kOhm
• Maximum Input Level: +24 dBu
• Maximum Power Consumption: 900 W
• Dimensions (H x W x D): 16.9" x 34.8" x 19.7" (430 x 885 x 500 mm)
• Weight: 160 lb (72.6 kg)

Adam Audio S5H Studio Monitor Includes

• ADAM Audio S5H Studio Monitor
• Power Cord
• User Manual
• Manufacturer Warranty
