The HLabs EQ169+ Mastering Equalizer is a single channel equalizer with exceptional musicality and enhanced performance - fully stepped controls, unique EQ gain range feature, selectable high-pass filter, two "presence" bands, secondary shelves frequencies & output gain.
Back in the day, EQing was the essential finishing step in ensuring the quality of the vinyl pressing. But it's also the final touch to the overall tonal balance of your track. With the EQ169+, HLABS taken inspiration from the circuit topology of the Studer console to create the perfect master, bus or track tone-shaping tool. For all users who always dreamed about a Studer-based extended four-band EQ, it becomes a reality!
EQ GAIN RANGE MODES
Access the three EQ gain ranges: a ‘original' mode with ±12dB on the presence bands and ±15dB on the shelves, a ‘hybrid' mode with ±12dB on the presence bands and ±5dB on the shelves, or a 'master' mode with ±4dB and ±5dB respectively for finer control.
FOUR BAND EQUALIZER
The equalizer introduces an extended set of filters, including a 10-position high-pass filter and a selectable low shelf tuned at either 20Hz or 60Hz to manage low-frequency build-up. Two midrange “presence” bands provide 22 selectable frequencies ranging from 150Hz to 7kHz, offering broad yet surgical control over the mids. A smooth, natural-sounding high shelf can be set at 20kHz or 35kHz, allowing engineers to add subtle air and brightness.
SIGNAL PATH
The inclusion of an output gain stage further enhances flexibility, especially in mastering chains. The EQ169+ features transformerless input and output stages for maximum transparency. It supports a maximum input and output level of +22dBU, with a frequency response flat within ±0.1dB from 5.4Hz to over 35kHz. With extremely low total harmonic distortion at 0.005% @ 0dBU and a signal-to-noise ratio exceeding 108dB, it guarantees pristine audio fidelity. The unit also presents high headroom with input and output impedances of 48kΩ and 50Ω, respectively.
HANDMADE IN FRANCE
With its robust build and meticulous engineering, the EQ169+ caters to engineers seeking high-resolution control in both mastering and tracking scenarios. Its feature-rich architecture makes it a worthy successor to classic Studer-based EQ designs while firmly placing it in the modern era.
HLabs EQ169+ Mastering Equalizer Features
- Mastering-grade equalizer combining the adjustable low cut filter (10 frequencies) and the low shelf (tuned @20 or 60 Hz) to tame the lows
- Two 'Presence' filters for a total of 22 different frequencies from 150 to 7 kHz to master the mids
- Very natural high shelf, tuned either at 20 or 35 kHz to air out the highs
- Three EQ gain ranges: original, hybrid or master
- Fully stepped 11-positions controls behind ALL knobs
- Transformerless I/O and adjustable output level ±3dB
- 100% discrete THT components and precision resistors and capacitors for ±0.1 dB matched gain between units
HLabs EQ169+ Mastering Equalizer Specifications
- High Pass Filter: 10 tuned frequencies, ranging from 12Hz to 160Hz + bypass
- High Shelf: @ 20kHz or 35kHz
- "Presence" Filters: from 150 to 7000Hz - Q ≈ 1.0
- Low Shelf: @ 20Hz or 60Hz
- Max Level (input & output): +22dBU
- Input Impedance: 48kΩ
- Output Impedance: 50Ω
- Frequency Response (1kΩ load): ±0.1dB from 5.4Hz to 25kHz+
- SNR: >108dB
HLabs EQ169+ Mastering Equalizer Includes
- HLabs EQ169+ Mastering Equalizer
- Power Cable
- Wooden Box
- Manufacturer Warranty
