The Mystery Magicians LBDI Tube Direct Box delivers the same uncompromising Class A tube tone as its rackmount sibling in a portable, desktop-friendly format designed for musicians, producers, and mobile studios.
Running its 12AU7 tubes at a full 320V, the LBDI produces natural harmonic richness, punchy transients, and wide dynamic range that elevate guitars, basses, synths, keys, and other Hi-Z sources. Compact yet powerful, the LBDI functions as a DI, instrument preamp, tone shaper, and reamping tool in a single all-tube package. The LBDI features a switchable High/Low gain input stage, allowing you to move from clean, articulate tones to rich tube saturation with ease. Its true bypassable three-band tube EQ offers musical control, while the intelligent Bright circuit dynamically adjusts high-frequency response based on input gain—maintaining clarity at low levels and smooth balance at higher drive settings. A dedicated reamp input makes it easy to process prerecorded tracks through the tube circuitry for added depth and character. Finished with a rugged steel chassis and a distinctive chromed carry handle, the LBDI is equally at home on top of an amp, on a desktop, or in a live rig.
Mystery Magicians LBDI Tube Direct Box Features
- Fully tube-based, Class A direct box and instrument preamp
- High-voltage design running 12AU7 tubes at 320V
- Portable “lunchbox” chassis with robust chromed carry handle
- Hi-Z input for passive and active instruments
- Switchable High / Low Gain front end
- Up to 53 dB of gain for instruments and high-impedance microphones (e.g. harmonica mics)
- True bypassable 3-band tube EQ
- Bass ±15 dB
- Mid ±6 dB
- Treble ±10 dB
- Gain-dependent Bright switch for enhanced clarity without harshness
- Dedicated Reamp XLR input for processing prerecorded tracks and stems
- Phase reverse switch
- Ground lift switch
- Front THRU output for amps, tuners, or parallel processing
- -20 dB balanced output pad
- Auto-sensing international power supply (86–260 VAC)
Mystery Magicians LBDI Tube Direct Box Specifications
- Circuit Type: All-tube, Class A
- Tubes: Philips ECG NOS 12AU7
- Hi-Z Input Impedance: 1 MΩ
- Reamp Input Impedance: 100 kΩ balanced
- Maximum Gain:
- High Gain: 53 dBu
- Low Gain: 32 dBu
- Reamp Input: 10 dBu
- Output Impedance: 150 Ω balanced
- Frequency Response: 5 Hz – 50 kHz (±0.5 dB)
- Maximum Output Level: +22 dBu @ 1% THD+N
- THD+Noise @ +4 dBu: 0.02% (second harmonic dominant)
- Power Requirements: 86–260 VAC, 50–60 Hz
Mystery Magicians LBDI Tube Direct Box Includes
- Mystery Magicians LBDI Tube Direct Box
- IEC Power Cable
- Manufacturer Warranty
